LEICA Construction / Earthmoving Laser Level Package - Rugby 820 LG790384

LEICA

$2,999.00
LEICA Construction / Earthmoving Laser Level Package Features: Leica Rugby 820 is used for: land levelling, align concrete forms, plumbing, machine control, excavation work, landscaping, building construction, alignment, site grading, construction stake out, concrete levelling, home building, and many various site tasks. Leica Rugby 820 is Tough, reliable and features dual...
Secure checkout
Free shipping over $50

LEICA Construction / Earthmoving Laser Level Package Features:

Leica Rugby 820 is used for: land levelling, align concrete forms, plumbing, machine control, excavation work, landscaping, building construction, alignment, site grading, construction stake out, concrete levelling, home building, and many various site tasks. Leica Rugby 820 is Tough, reliable and features dual slope levelling! Best value construction laser level.

Dual Axis Slope
The Leica Rugby 820 can be manually set through the keypad for up to 10% in single or dual-axis.

Smart Targeting
The Smart Targeting system allows the operator to automatically dial on the slope required through the Leica Rod Eye 180 RF unit. Simply set up your laser of the starting point take the Leica Rod Eye 180 RF to the second point and let Leica Smart Targeting system do the work for you.

Smart Lock
With the Smart Lock function, the laser plane is always monitored in real time ensuring that no mistakes can be made. Should the laser plane move out of tolerance, the laser will indicate the movement with an alarm.

Toughest laser in the market
The Leica Rudgy 800 series introduces the toughest range of laser levelling instruments. Protected by an outer case of rubber moulded around the hard tough plastic case to provide maximum protection and a soft grip to handle.

Designed to IP68 protection against water and dust, the Leica Rugby 800 series has Military Grade Certification (MIL-STD 810G ) to ensure that the laser will work in the harshest environments. This includes maximum temperature stability across the entire operating temperature range. Automatic self levelling Construction laser. Indoor Outdoor Rotating Laser Level.

Unique power Concept
Interchangeable battery packs: Alkaline battery, Li-ion battery
Run and charge anywhere: In the car from a 12v battery / generator or out in the sun with the solar panel. The solar panel kit will charge the Leica Rugby's Li-ion battery unit.

Lifetime Warranty
With all products manufactured by Leica Geosystems, the Leica Rugby has been designed to function day-in-day-out. But when an accident happens and the laser is knocked over, the instrument provides a 2 year knockdown warranty alongside the extended 5 year warranty.

LEICA Construction / Earthmoving Laser Level Package Specifications:

Technical data
Leica Rugby 810
Leica Rugby 820
Leica Rugby 830
Leica Rugby 840
Functionality
Self-levelling horizontal, single manual slope (with slope adpater)
Self-levelling horizontal & manual slope in dual axis
Self-levelling horizontal & manual slope in dual axis
Self-levelling horizontal, vertical, 90° and manual slope in dual axis
Smart Targeting
            Smart Lock




Operating range (diameter)
800 m (2,600 ft)

1,350 m (4,300 ft)
700 m (2,300 ft)
Self-levelling accuracy*
± 1.5 mm at 30 m (± 1/16"" at 100 ft)

Self-levelling range
± 6°
Rotation speed
10 rps
0, 2, 5, 10 rps
Laser diode type
635 nm (visible)
Scanning modes
-
-
-
10°, 45°, 90°
Laser class
Class 2
Dimensions (HxWxD)
235 x 238 x 190 mm (9.2 x 9.4 x 7.5 in)
Weight with batteries
3.0 kg (6.6 lbs)
Batteries alkaline / rechargeable
Four D-cells / Li-Ion pack
Battery life alkaline / rechargeable**
60 hours / 45 hours @ 20°C
Maximum Temperature Stability
-20° to +50°C
(-40° to +122°F)
-20° to +60°C
(-40° to +142°F)
-20° to +50°C
(-40° to +122°F)
Storage temperature
-40° to +70°C (-40° to +158°F)
Environmental standard
IP68
RC400 remote control Operating range
-
-
-
200 m (650 ft)
(diameter)
LEICA Construction / Earthmoving Laser Level Package Includes:
  • Leica Rugby 820
  • Digital Receiver Rodeye 160
  • Alkaline Batteries
  • Manual
  • Hard carry caseÃâ
SKU
LG790384
Weight
232.0 kg
