LEICA
ISO Standard 16331-1 "° The standard for laser distance meters
The range and accuracy of laser distance meters depend on light conditions and reflectivity of the measuring target. For Leica Geosystems it is important that the instruments not only perform under perfect laboratory conditions, but above all under the kind of everyday working conditions encountered on construction sites. This is why, working together with external experts, the company have developed a standard by which laser distance meters can be tested and compared with each other.
  Â
Robust housing
The sensitive measuring elements are protected by solid rubber parts. Proven in drop tests from up to 2 m height, the Leica DISTO X310 is therefore particularly resistant.
Â
    Â
Protection class IP65
The housing and keypad are specially sealed against water and dust. Cleaning under running water is also no problem.
 Â
Tilt sensor 360°
Thanks to the combination of distance and tilt measurements, you can determine the horizontal distance absolutely precisely and simply "° even past obstructions. With the help of the tilt sensor, you can also determine indirect heights.
    Â
Smart Horizontal Mode
If obstructions prevent you from taking direct distance measure-ments, you can use the Smart Horizontal Mode to determine the horizontal distance simply and absolutely precisely.
| Technical specifications: | |
| Typical measuring accuracy | å± 1 mm |
| Range | up to 80 m |
| Measuring units | 0.000 m, 0.0000 m, 0.00 m, 0.00 ft, 0"°ÃƒºÃƒÂ·00"°ÃƒºÃƒÂ·"°ÃƒºÃƒÂ· 1/32, 0.0 in, 0 in 1/32 |
| Power Range Technology | |
| Distance in m Ì÷ of the laser dot in mm | 10, 50, 100 m 6, 30, 60 mm |
| Protection class | IP65 "° water jet protection and dust-tight |
| Measurements per set of batteries | up to 5000 |
| Batteries | type AAA 2 ÌØ 1,5 V |
| Dimensions | 122 ÌØ 55 ÌØ 31 mm |
| Weight with batteries | 155 g |
| Functions: | |
| Min/max measurement | |
| Continuous measurement | |
| Stake out function | |
| Addition/subtraction | |
| Area/volume | |
| Painter function | |
| Pythagoras | 3 points, partial height |
| Smart Horizontal Mode | |
| Height tracking | |
| Memory | 20 Displays |
| Illuminated display | |
| Multifunctional end-piece | with automatic recognition |
