TOPCON Taurus Red Beam Construction Laser Kit RLH3D

The Topcon Taurus is a Japanese made laser & is the perfect for all of your general purpose construction applications. Hit the power button and get to work in seconds. The Taurus is the perfect tool for quick and accurate grading and excavation work. This self-leveling laser makes every job faster and easier. From checking grades and excavations, to setting forms for concrete, to general building, Taurus makes it easy. With a long 300m working range, you can work almost any site with only one set up. Best of all, Taurus is simple and reliable to use, with accuracy that is unbeatable. For added protection, if the laser is disturbed, it shuts off and gives an alert so you don’t go off-grade. The full-featured LS-1 laser detector has dual-sided LCD displays and audible signals to quickly guide you to grade. You can select from two on-grade tolerances. Taurus, the new standard in affordable construction lasers.

STANDARD KIT CONTENTS: Taurus 2LS Laser Level LS-1 Laser Receiver 4 x C batteries 2 x AA batteries for LS-1 Receiver Holder Carry Case

FEATURES:

• Accuracy, ±2mm over 20m
• 60 hours battery life
• 300m range
• Eye safe infrared laser beam
• Fully self leveling
• Built Topcon Tough Machine control compatible

TAURUS 2LS LASER SPECIFICATIONS:

• Accuracy: ±2mm over 20m
• Automatic Correction Range: ±3°
• Operating range (diameter): Approx. 4m to 300m with LS-1
• Rotation speed: 600 r.p.m.
• Laser source: Laser diode (635nm)
• Laser output: 2.4mW Safety standard for laser beam: DRH (FDA) Class IIIa, IEC Class 3R
• Water and dust resistance: IP56
• Operating temperature: -20âžÆ’ to +50âžÆ’
• Power supply: 4x C size dry cells (alkaline)
• Operating time: Approx. 60 hours at +20âžÆ’
• Weight: 2kg (including batteries)
• Dimensions: 167 x 192.5 x 189mm
• Warranty: 24 months

TOPCON LS-1 RECEIVER SPECIFICATIONS:

• Minimum distance from laser: Approx. 2-4m
• Beam detection window: 45mm
• Beam detection precision: High precision: ±1mm / Normal precision: ±2mm
• Beam detection indication: Liquid crystal (both sides) and buzzer
• Power supply: 1x 9v dry cell battery
• Operating time: Approx. 35hours
• Auto shut-off delay: Approx. 20 min without beam detection
• Water and dust resistance: IP65 Operating temparature: -20âžÆ’ to +50âžÆ’
• Weight: 196g
• Dimensions: 135 x 65 x 24.5mm
